  Marca: Asus
•
  Modelo: PRIME B360-PLUS
•
  Compatibilidade de CPU: LGA1151 socket for 8th Generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron® processors
•
  Chipset: Intel® B360 Chipset
•
  Memória:
  4 x DIMM, maximum 64 GB, DDR4 2666/ 2400/ 2133MHz, non-ECC, unbuffered memory
  Dual channel memory architecture
  Supports Intel® Extreme Memory Profile (XMP)
•
  Lan: Realtek® 8111H Gigabit LAN support LANGuard
•
  Suporte Multi-GPU: Supports AMD® CrossFireX™ Technology
•
  Suporte ao Sistema Operacional: Windows® 10 (64-bit)
•
  Formato: ATX form factor: 12.0 in. x 8.7 in. (30.5 cm x 22.1cm)
•
  Gerenciabilidade: WOL by PME, PXE
•
  Bios:
  128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen,  and ASUS DRAM SPD (Serial Presence Detect) memory information
•
  ASUS Quiet Thermal Solution:
  Quiet Thermal Design:
   ASUS ASUS Fan Xpert 2+
   Stylish Fanless Design: PCH Heat-sink & MOS Heat-sink
•
  USB:
  Intel® B360 Chipset
  2 x USB 3.1 Gen 2 (up to 10Gbps) ports (2 ports @back panel, teal blue, Type A)
  4 x USB 3.1 Gen 1 (up to 5Gbps) ports (2 ports @mid-board; 2 ports @back panel, blue, Type A)
  6 x USB 2.0/1.1 ports (2 ports @mid-board; 4 ports @back panel)
•
  Acessórios:
  2 x SATA 6Gb/s cables
  1 x IO Shield
  2 x M.2 screws
  1 x Support DVD
  1 x User's manual
•
  Slots de Expansão:
  1 x PCI Express 3.0/2.0 x16 slot (at x 16 mode)
  1 x PCI Express 3.0/2.0 x16 slot (max. at x4 mode, compatible with PCIe x1, x2 and x4 devices)*
  2 x PCI Express 3.0/2.0 x1 slots
  2 x PCI slots
•
  Armazenamento:
  Intel® B360 Chipset
  1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode & X2 PCIE mode)*
  1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (X4 PCIE mode)
  6 x SATA 6.0 Gb/s ports (gray)
  Intel® Optane™  Memory Ready**
•
  Áudio:
  Realtek® ALC887 8-channel* high definition audio CODEC
  LED-illuminated design: Brighten up your build with the gorgeous illuminated audio trace path.
  Audio Shielding: Ensures precision analog/digital separation and greatly reduces multi-lateral interference
  Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
  Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity.
  Supports jack-detection and front panel jack-retasking
•
  VGA:
  Integrated Graphics Processor- Intel® HD Graphics support
  Multi-VGA output support: HDMI/DVI-D/D-sub port
  Supports HDMI 1.4b with max. resolution 4096 x 2160@24Hz / 2560 x 1600@60Hz
  Supports DVI-D with max. resolution of 1920 x 1200 @60Hz
  Supports D-sub with max. resolution 1920 x 1200@60Hz
  Supports Intel® InTru™ 3D/Quick Sync Video/Clear Video HD Technology/Insider™
  Supports up to 3 displays simultaneously
  Maximum shared memory of 1024 MB (for iGPU exclusively)
•
  Painel traseiro e Portas I/O:
  1 x PS/2 keyboard/mouse combo port
  1 x HDMI port
  1 x DVI-D port
  1 x D-sub port
  1 x LAN (RJ45) ports
  2 x USB 3.1 Gen 2 (up to 10Gbps) Type A (teal blue)
  2 x USB 3.1 Gen 1 (up to 5Gbps) Type A (blue)
  4 x USB 2.0/1.1 ports
  3-Jack 8-Channel Audio I/O ports
•
  Conectores internos:
  ASUS 5X PROTECTION III
  ASUS SafeSlot Core: Fortified PCIe with solid soldering
  ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
  ASUS Overvoltage Protection: World-class circuit-protecting power design
  ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
  ASUS DIGI+ VRM: 6 Phase digital power design
  Superb Performance
   ASUS OptiMem
  Improved DDR4 stability
  M.2 onboard
  The latest transfer technologies with up to 32Gb/s data transfer speeds
  ASUS Fan Xpert 2+
  Ultimate cooling and quietness
  ASUS EPU
  EPU
  UEFI BIOS
  Most advanced options with fast response time
  Gaming Scenario
  Audio Features
  Audio that roars on the battlefield
  ASUS Exclusive Features
  ASUS Ai Charger
  ASUS AI Suite 3
  ASUS file transfer
  ASUS PC Cleaner
  EZ DIY
  UEFI BIOS EZ Mode
  featuring friendly graphics user interface
  ASUS CrashFree BIOS 3
  ASUS EZ Flash 3
  Q-Design
  ASUS Q-DIMM
  ASUS Q-Slot
